Solar Power Testers
Sub Categories
| Name | Description | Category | ||
|---|---|---|---|---|
|
TES0026-1333R Datalogging Solar meter | TS-1333R Datalogging Solar Power Meter Order no: TES0026 (Confirmed in stocks) Wide spectral range. Excellent long term stability. Cosine corrected. Automatic transmission measurements. Select either power or transmission. Solar energy power or transmission. Current time setting function. User calibration factor setting function. End-mount light sensor. Select either W/m2 or Btu / (ft2*h) units Data Hold / MAX / AVG modes. Data Memory and Read function. (99 sets.) Auto Data memory and RS232 interface to PC. (TES-1333R) Meteorology agriculture solar radiation measurement solar power research physics and optical laboratories solar transmission measurement identify high performance windows Display 3-1/2 digits.Max.indication1999 Range 2000W/m 2 、634Btu/(ft 2 * h) Resolution 1W/m2、1Btu/(ft2*h) Spectral response 400-1100nm Accuracy Typically within ± 10W/m2[ ±3 Btu / (ft2*h) ] or ±5% , whichever is greater in sunlight; Additional temperature induced error ±0.38W/m2 / ℃ [... | Datalogger/Recorders |
|
|
PRO0044-210V2 SOLAR PANEL ANALYSER / I-V CURVE PHOTO-VOLTAIC PV TRACER 60V 12A | I-V Curve Test for Solar Cell. Maximum Solar Power (Pmax) Search by Auto-scan (60V, 6A) Maximum Voltage (Vmaxp) at Pmax Maximum Current (Imaxp) at Pmax Voltage at open circuit (Vopen) Current at short circuit (Ishort) I-V curve with cursor Optional printer (model: 300XP) to hardcopy I-V curve Calculation of Efficiency (%) Manual single point test | Datalogger/Recorders |
|
|
PRO0044B-1010V2 (NEW 1011) SOLAR SYSTEM ANALYZER 1000V, 12A | ●I-V curve test for solar system ●Continuous monitoring output power, watt hour, efficiency of solar system and inverter ●Max. solar system power (Pmax) search by Auto-scan: 1000V, 12A ●Max. voltage (Vmaxp) and Max. current (Imaxp) at Pmax ●Voltage at open circuit (Vopen), Current at short circuit (Ishort) ●Temperature measurement of solar panels, Irradiance measurement of sun light, series resistance (Rs) calculation of solar panels ●Real time data logging, built-in calendar clock ●Efficiency (%) calculation of solar panels ●Conversion of I-V curve under OPC to data under standard test condition (STC) based upon IEC standard ●Provide Operating Condition (OPC) and Standard Test Condition (STC) test reports for verification of solar panel performance (OK, or NO OK) ●With optional power clamps (SOLAR 15 and SOLAR 21), measure/record DC power output of solar system and AC power output of inverter (1 phase or balanced 3 phase); calculate efficiency of DC to AC power conversion and max. power ●Parameter setting of solar panels; setting for number of solar panels in a string ●Rechargeable lithium battery, low battery warning... | Datalogger/Recorders |
|
|
SEA3101- SOLAR SURVEY 200R DATAOGGING IRRADIANCE METER (Datalogging)-From UK | Measures irradiance as required by IEC 62446 Built-in compass and inclinometer measure roof orientation and pitch Dual channel temperature measurement 200R features Seaward Solarlink™ for wireless connectivity with the PV150 Solar Installation tester (available seperately) Built-in data logger and USB interface (Solar Survey 200R model only) Suitable for both photovoltaic and solar thermal installations Supplied with calibration certificate Rugged, robust and handheld | Solar Power Testers |
|
|
SEA3100- SOLAR SURVEY 100R IRRADIANCE METER (No datalogging)-From UK | Measures irradiance as required by IEC 62446 Built-in compass and inclinometer measure roof orientation and pitch Dual channel temperature measurement 200R features Seaward Solarlink™ for wireless connectivity with the PV150 Solar Installation tester (available seperately) Built-in data logger and USB interface (Solar Survey 200R model only) Suitable for both photovoltaic and solar thermal installations Supplied with calibration certificate Rugged, robust and handheld | Solar Power Testers |
|
|
SEA3200-SOLAR PV 150 MULTIFUNCTION SOLAR INSTALLATION KIT - FROM UK | Combines all electrical tests required by MCS and IEC 62446 Memory for up to 200 records USB download to PC Records irradiance wirelessly (separate SolarSurvey 200R required) Single key testing and measurement Safe test connection with energised PV arrays | Solar Power Testers |
|
|
SEA3300-SEAWARD MCS SOLARLINK COMPLETE TEST KIT WITH CLAMP AND CERT- FROM UK | Combines all PV electrical test functions into one tester Records irradiance and temperature simultaneously to electrical tests being conducted Stores up to 200 complete test records USB download to PC Simple, fast and comprehensive PV testing | Solar Power Testers |
|
|
TEN320-TEN320-Basic Solar Power Meter(W/CM2,BTU) | - 3½ digits LCD display with maximum reading of 2000. - Measuring the Solar radiation emitted by the sun. - Display units: W/m2 (Watts per square meter) or BTU. - Data Hold/ MAX/MIN functions. | Solar Power Testers |
|
